Supporting SIP 2.0 and IMS platform
Duplex hands-free, providing voice quality for carrier-class
Password to open the door
RFID card to open the door
Remote to control the door

The basic features
Supporting SIP 2.0 and IMS platform of operators, and Interconnecting with the mainstream manufacturers IPPBX
Embedding BRODCOM chip, Stable and reliable
duplex hands-free, providing voice quality for carrier-class
Supporting the password to open the door 、the RFID card to open the door、the remote to control the door
A button calls to any one terminal or more terminals(RingGroup )
Supporting visitors to leave a message, and the owner play back the message by the SIP phone
Supporting three calls or Multiparty calls (multi-party meeting)
Once access to the network, it can be used
Providing online software upgrades and WEB management

Business: Office, shopping center
Education: University, school, stadium
Health: Hospital, laboratory, pharmaceutical plant
Logistics and Transport: Airport, car park and garage
Industry: Factory and Product Center

Technical parameters
communication protocol Interface
Support SIP 2.0(RFC3261)and Relevant RFC
power supply mode 12V+-15%/1A DC or PoE
PoE 802.3af (Class 0 – 12.95W) 48V/380mA
Speed dial button The buttons adopt stainless steel,sturdy and durable LAN 10/100BASE-TX s Auto-MDIX, RJ-45)
Speed dial button number one The recommended cable five or more
Digital keys Adopt Touch Button
Passive switch Often open and close, maximum achievable 30V/1A AC/DC
Voice The active switch output 12V/500mA DC
microphone one The structural characteristics
Speaker 1W Shell Material surface cover Aluminum,plastic pan
Hands-free and full-duplex support Working temperature 0°C to 55°C
Audio stream Environmental relative humidity 10% – 95%
Support agreement RTP Storage Temperature -40°C to 70°C
CODEC G.711,G.729,G.722,GSM,G.726,iLBC installation Pit mounted(pre-bury )
RFID Dimension overall dimensions:174.5╳96╳44mm
EM-40XX(125KHz) Installation dimensions:148╳80╳36mm
